5M 300-Light TM1814 LED Digital Strip DC 12V 24V 10 or 20 Pixel/M SMD 5050 RGBW RGBWW 4 in 1 Addressable Magic Color Light Strip

Model number: FD-SMD5050-03
Colour: RGB Addressable
Inventory:

Overview:> > 12V: TM1814-RGBW 4 colors in 1 Addressable Flex led strips, 60led/m, Control IC built outside, 20pixel/m, 12V, 14.4w/m,10mm white or black PCB, 15cm JST connector;> 24V: TM1814-RGBW 4 colors in 1 Addressable Flex led strips, 60led/m, Control IC built outside, 10pixel/m, 2

Product details

5M 300-Light TM1814 LED Digital Strip DC 12V 24V 10 or 20 Pixel/M SMD 5050 RGBW RGBWW 4 in 1 Addressable Magic Color Light Bar

Overview:

> > 12V: TM1814-RGBW 4 colors in 1 Addressable Flex led strips, 60led/m, Control IC built outside, 20pixel/m, 12V, 14.4w/m,

10mm white or black PCB, 15cm JST connector;
> 24V: TM1814-RGBW 4 colors in 1 Addressable Flex led strips, 60led/m, Control IC built outside, 10pixel/m, 24V, 14.4w/m,

10mm white or black PCB, 15cm JST connector;

Features:

1) Addressable DC12V/24V TM1814-RGBW/RGBWW LED Strips; Long life span 50,000+ hours;
2) Super bright 5050 SMD top LED, high intensity and reliability;
3) Absolutely addressable, TM1814- IC built outside;
4) TM1814 has 3 Wires input and output: Data, GND and Power+;
5) 12V Three leds one cut; 24V Six leds one cut
6) PWM 2KHz/m, Data transmit up to 800kbps, 256 grayscale effect;
7) 12V Each IC control 3 leds;24V Each IC control 6 leds

Product Model	TM1814 Magic Light Bar
Light source	SMD 5050 4 in 1 LED (RGBW or RGBWW)
Light strip material	Flexible PCB
IC model	TM1814, 1 IC controls 3 or 6 LED lights)
LED Quantity	60 lights/meter, every 3 or 6 lights is a group, which can be cut;
Lighting angle	120°
Lighting color	any color can be achieved by adjusting the controller
Standard working voltage	DC 12V or 24V
Power	14.4 W/M
Waterproof grade	waterproof IP67; waterproof IP65; non-waterproof IP20
Dimensions of FPCB board	Width: 10 mm, IP67(12 mm)
FPCB color	White
Packing method	5m / roll, 3M glue on the back of the light bar (IP67 without back glue), electrostatic bag packaging;
Note: 12V Addressable Groups of 3 LEDs , 3 LEDs/Pixel; 24V Addressable Groups of 6 LEDs , 6 LEDs/Pixel
Light up 1 color (red or green or blue) 0.06W/LEDs . Light up all 0.24W/LEDs

Product Applications:

1) Light up colorful home life, DIY household lights for hallways, stairs, trails ,windows.
2) Hotels decoration use,Theaters, clubs, shopping malls, festivals and performances use.
3) Architectural decorative lighting, Archway, canopy and bridge edge lighting, Security lighting and Emergency.
4) Extensively applied in Backlighting for signage letters, concealed lighting and advertisement sign lighting.
5) Applicable for automobile & Airplane model decoration, contour lighting or border.
